| Part Details | |||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Details | Price (USD) | Global Stock | Lead Time | Date Code | Package | Package Style | Type | Isolation | No of Outputs | Output Power | Output Voltage | Input Voltage | Operating Temp Range | Efficiency | Load Capacitance | Load Regulation (%) | Output Current | Switching Frequency-Max | Ripple & Noise | Dimension | Mounting Feature |
| Qty Unit Price 1 $10.23 4 $10.09 15 $9.96 25 $9.91 50 $9.75 | 286 Ready to Ship! | 16 Weeks | 2422 | Box | |||||||||||||||||
| Qty Unit Price 1 $105.74 2 $104.20 3 $103.31 4 $102.68 5 $100.70 | 45 Ready to Ship! | 16 Weeks | 2425 | Box | Encapsulated | Isolated | Single | 240W | 24V | 33.6V to 67.2V | -40°C to +70°C | 91% | 1% | 10A | 80mV | L 113.5mm x W 40mm x H 125.2mm | DIN Rail Mount | ||||
| Qty Unit Price 1 $20.20 3 $19.93 5 $19.80 20 $19.46 30 $19.24 | 1 Ready to Ship! | 16 Weeks | 2118 | Bulk | DIP-5 | Encapsulated | Isolated | Dual | 10W | -15/15V | 18V to 36V | -25°C to +71°C | 80% | 333mA | 250kHz | 50mV | L 50.8mm x W 25.4mm x H 11.3mm | Through Hole | |||
 RSP-500-48 MEAN WELL RSP-500 Series 504 W Single Output 48V Encapsulated PFC Function AC/DC Converter | Qty Unit Price 1 $99.33 2 $97.89 3 $97.05 4 $96.46 5 $94.60 | 0 | 17 Weeks | Bag | Encapsulated | Isolated | Single | 500W | 48V | 85V to 264V | PCB Mount | ||||||||||
| Qty Unit Price 1 $19.69 3 $19.42 5 $19.30 20 $18.97 30 $18.75 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 12W | 12V | 36V to 72V | PCB Mount | |||||||||||
| Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 12V | 9V to 18V | -40°C to +70°C | 88.5% | 1% | 8.3A | 50mV | DIN Rail Mount | ||||||
| Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 4.2V | 9V to 18V | -40°C to +70°C | 88.5% | 1% | 4.2A | 50mV | DIN Rail Mount | ||||||
| Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 48V | 9V to 18V | -40°C to +70°C | 88.5% | 1% | 50mV | ||||||||
 DDR-120B-12 MEAN WELL DDR-120 Series 120 W 16.8 to 33.6 V Input 12 V Output DIN Rail DC/DC Converter | Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 12V | 16.8V to 33.6V | -40°C to +70°C | 89% | 1% | 10A | 50mV | DIN Rail Mount | |||||
| DDR-120B-24 MEAN WELL DDR-120 Series 120 W 16.8 to 33.6 V Input 24 V Output DIN Rail DC/DC Converter | Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 24V | 16.8V to 33.6V | -40°C to +70°C | 89.5% | 1% | 5A | 50mV | DIN Rail Mount | |||||
| DDR-120B-48 MEAN WELL DDR-120 Series 120 W 16.8 to 33.6 V Input 48 V Output DIN Rail DC/DC Converter | Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 48V | 16.8V to 33.6V | -40°C to +70°C | 91% | 1% | 2.5A | 50mV | DIN Rail Mount | |||||
| DDR-120C-12 MEAN WELL DDR-120 Series 120 W 33.6 to 67.2 V Input 12 V Output DIN Rail DC/DC Converter | Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 12V | 33.6V to 67.2V | -40°C to +70°C | 89.5% | 1% | 10A | 50mV | DIN Rail Mount | |||||
| DDR-120C-24 MEAN WELL DDR-120 Series 120 W 33.6 to 67.2 V Input 24 V Output DIN Rail DC/DC Converter | Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 24V | 33.6V to 67.2V | -40°C to +70°C | 91% | 1% | 5A | 50mV | DIN Rail Mount | |||||
| DDR-120C-48 MEAN WELL DDR-120 Series 120 W 33.6 to 67.2 V Input 48 V Output DIN Rail DC/DC Converter | Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 48V | 33.6V to 67.2V | -40°C to +70°C | 92% | 1% | 2.5A | 50mV | DIN Rail Mount | |||||
| Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 12V | 67.2V to 154V | -40°C to +70°C | 89.5% | 1% | 10A | 50mV | DIN Rail Mount | ||||||
| Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 24V | 67.2V to 154V | -40°C to +70°C | 91% | 0.5% | 5A | 50mV | DIN Rail Mount | ||||||
| Qty Unit Price 1 $70.67 2 $69.79 3 $69.29 5 $68.65 10 $67.30 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 120W | 48V | 67.2V to 154V | -40°C to +70°C | 91.5% | 1% | 2.5A | 50mV | DIN Rail Mount | ||||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 15W | 12V | 9V to 36V | -40°C to +85°C | 1200µF | 0.5% | 1.25A | 60mV | DIN Rail Mount | ||||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 15W | 24V | 9V to 36V | -40°C to +85°C | 0.63A | DIN Rail Mount | |||||||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 15W | 5V | 9V to 36V | -40°C to +85°C | 3A | DIN Rail Mount | |||||||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 15W | 12V | 18V to 75V | -40°C to +85°C | 86% | 1200µF | 0.5% | 1.25A | 60mV | DIN Rail Mount | |||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | ||||||||||||||||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | ||||||||||||||||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 15W | 24V | 18V to 75V | -40°C to +85°C | 87% | 680µF | 0.5% | 0.63A | 100mV | DIN Rail Mount | |||||
| Qty Unit Price 1 $21.11 3 $20.82 5 $20.69 20 $20.34 30 $20.10 | 0 | 16 Weeks | Box | Encapsulated | Isolated | Single | 15W | 5V | 18V to 75V | -40°C to +85°C | 85% | 3300µF | 1% | 3A | 50mV | DIN Rail Mount |
