Manufacturer Part #
102241-3
AMPMODU 5 Position Single Row 2.54 mm Pitch Wire Applied Detent Latching Housing
| | |||||||||||
| | |||||||||||
| Mfr. Name: | TE Connectivity | ||||||||||
| Standard Pkg: | Product Variant Information section Available PackagingPackage Qty:500 per Box | ||||||||||
| Date Code: | 2440 | ||||||||||
TE Connectivity 102241-3 - Product Specification
Shipping Information:
ECCN:
PCN Information:
Description of Changes:1. Please be aware the 108-25020 document have been updated to improve clarity, product speci cations for di erent pressure type contacts 108-25007 and 108-25021 is incorporated into one specification 108-25020. 2. There is a change in contact retention force- Before: contact retention force applied with 5 Lbs axial load. After: contact retention force Applied with 3 Lbs axial load. 3. The contact retention force has been adjusted from 5 lbs to 3 lbs (axial load). 4. Product performance (electrical / environmental) remain unchanged. 5. In the attached test report, PN 87922-4 was tested as a representative sample for the affected part numbers listed belowReason for Changes:1. Resin change to LCP in the MOD IV family 2. Standardizing product requirements similar to Product like MTE receptacle and short point contact receptacle.
General Product Description: Low to high temp material change Description of Changes This is to notify customers that an existing low temperature housing material will be replaced with a high temperature LCP material. The use of the new material provides a functional advantage in high temperature applications. There will be no change to the product's form, fit, function. It operates under a certified quality management system. The transfer follows a strict procedure, which fully maintains the quality, ability to supply, and form-fit-function of the concerned products. Product Category: Connector HousingsChange Feature: Material ChangeKind of Change:MaterialPotential Customer Impact: Risk mitigationFirst Ship Date of Changed Items (Changed Parts Only): 29-JUL-2022
Part Status:
TE Connectivity 102241-3 - Technical Attributes
| Type: | Housing |
| No of Positions: | 5 |
| Pitch: | 2.54 mm |
| Style/Orientation: | Free Hanging Socket/Receptacle |
| Termination: | Crimp |
Features & Applications
Available Packaging
Package Qty:
500 per Box
