Vishay SIJH Power MOSFETs

Power MOSFETs in space-saving package run at up to 175°C

Vishay has extended its range of low-voltage N-channel power MOSFETs that benefit from the high thermal performance and space-saving properties of the PowerPAK® 8 x 8L package.

Like the other TrenchFET® MOSFETs in the series, the new 60 V SiJH600E and 80 V SiJH800E and SiJH5800E offer low on-resistance and withstand operating temperatures up to 175°C.

The PowerPAK package has gullwing leads and solder jointing for reliable operation over a long lifetime. The package characteristics include low thermal resistance for good heat dissipation. The PowerPAK 8 x 8L also has a 50% smaller footprint than a TO-263/D2PAK package, allowing for use in tightly populated board layouts, and resulting in high power density.

The SiJH MOSFETs are intended for use in functions including ORing and synchronous rectification.

Part Number	Maximum Drain-source Voltage	On-resistance at 10 V	Gate Charge at 10 V	Maximum Continuous Drain Current
SiJH440E	40 V	0.96 mΩ	279 nC	200 A
SiJH600E	60 V	0.92 mΩ	141 nC	373 A
SiJH800E	80 V	1.55 mΩ	140 nC	299 A
SiJH112E	100 V	2.8 mΩ	106 nC	225 A
SiJH5700E	150 V	4.1 mΩ	93 nC	174 A
