STMicroelectronics STM32WB15 Wireless MCU

Dual-core wireless MCU offers Bluetooth Low Energy capability

The STM32WB15 from STMicroelectronics is a dual-core wireless microcontroller which can provide comprehensive Bluetooth^® Low Energy connectivity while also running the host application. The Bluetooth v5.2 protocol stack is provided and supported by ST free of charge.

The STM32WB15 includes a 2.4 GHz radio managed by a dedicated Arm^® Cortex^®-M0+ processor core. To run the main application, it features a 64 MHz Cortex-M4 core which allows for uninterrupted real-time performance.

Highly integrated, the device includes a radio balun, and an embedded dc-dc step-down converter, reducing the need for external components. It also provides a rich selection of analog peripherals, including a 12-bit ADC and low-power comparator, multiple digital interfaces, and up to 37 fast I/Os, 35 of which are 5 V-tolerant.

STM32WB products are supported by the proven STM32Cube software ecosystem, which offers embedded software libraries and tools.

Features

High RF performance:
- Programmable output power up to +5.5 dBm
- 95.5 dBm sensitivity
- 2 Mbits/s maximum data rate
Rich security capabilities:
- Secure firmware installation
- Hardware encryption
- Hardware public key authority
- Secure 96-bit ID
- True random number generator
Memory resources:
- 320 kbytes Flash memory
- 48 kbytes SRAM
- Seven-channel DMA

Applications

Fleet and resource management
Asset monitoring and tracking
Large-scale IoT applications

Development Board

Board Part Number: NUCLEO-WB15CC

ARDUINO Uno V3 connectivity support and ST morpho headers provide an easy way to expand the functionality of the STM32WB15CC Nucleo open development platform with a wide choice of specialized shields.
